XM-25 Stainless Steel,Precipitation Hardened Martensitic Stainless Steel

XM-25 Stainless Steel

XM-25 Stainless Steel is Martensitic Age-hardenable Stainless Steel, UNS S45000 is the UNS number. And Alloy 450 is the common industry name. very good corrosion resistance with moderate strength, resists atmospheric corrosion including salt water atmospheres, excellent resistance to rusting and pitting in 5 and 20% salt spray at 35°C and oxidation up to 650°C, maximum service temperature for continuous service is 425°C. Niobium content minimum is 8 times the carbon content. XM-25 Hot-finished or cold-finished rounds, squares, hexagons, bar shapes included. these shapes may be produced by hot rolling or forging, acc. to UNS S45000, AMS 5763, ASME SA564 (XM-25), T S45000, ASME SA 705 (XM-25), ASTM A564 (XM-25), ASTM A693 (XM-25), ASTM A705 (XM-25). XM-25 shall be furnished in the solution-annealed condition, or in the equalized and oven-tempered condition. XM-25 may be furnished in the solution-annealed or aged condition. XM-25 shall be subjected to tension, impact, and hardness tests. main use for the pulp and paper industry, Medical devices, Aircraft parts, Power generation, Chemical processing, Nuclear. This page shows summary ranges across all of XM-25 them.

XM-25 / UNS S45000 / Custom 450 Datasheet

XM-25 Stainless Steel Applications

Pulp and paper, aerospace, power generation, chemical processing, nuclear applications, medical devices

XM-25 Stainless Steel Chemical Composition

Grade Spec. C Si Mn P S Cr Ni Mo Cu Nb
XM-25 Stainless Steel ASTM A564, ASTM A693, ASTM A959 ≤0.05 ≤1.00 ≤1.00 ≤0.030 ≤0.030 14.00-16.00 5.00-7.00 0.50-1.00 1.25-1.75 min 8xC
UNS S45000 AMS 5763, AMS 5773, AMS 5859, AMS 5863 ≤0.05 ≤1.00 ≤1.00 ≤0.030 ≤0.030 14.00-16.00 5.00-7.00 0.50-1.00 1.25-1.75 min 8xC

XM-25 Stainless Steel Mechanical Properties acc. to ASTM A564

Solution Treatment Condilion

  • 1900 ±25oF[1040oC ±15oC](Cool rapidly)
    • Tensile Strength, min, ksi[MPa]: 125 * Maximum 165 ksi[1140 MPa] tensile strength only for sizes up to 1/2 in.(13 mm).
    • Yield Strength, min, ksi[MPa]: 95[655]
    • Elongation Reduction in 2 in. [50mm] or 4D, min %: 10
    • Reduction of Area, min %: 40
    • Hardness
      • Rockwell: max 32
      • Brinell: max 321

Hardening + Aging Treatment

  • Condilion H900
    • Tempperature: 900oF[480oC]
      • Tensile Strength, min, ksi[MPa]: 180[1240]
      • Yield Strength, min, ksi[MPa]: 170[1170]
      • Elongation Reduction in 2 in. [50mm] or 4D, min %: up to 12 in. Incl, L: 10; T:6
      • Reduction of Area, min %: up to12 in. Incl, L: 40; T:20
      • Hardness
        • Rockwell: min 39
        • Brinell: min 363
      • impact Charpy-V, min --
  • Condilion H950
    • Tempperature: 950oF[510oC]
      • Tensile Strength, min, ksi[MPa]: 170[1170]
      • Yield Strength, min, ksi[MPa]: 160[1100]
      • Elongation Reduction in 2 in. [50mm] or 4D, min %: up to 12 in. Incl, L: 10; T:7
      • Reduction of Area, min %: up to12 in. Incl, L: 40; T:22
      • Hardness
        • Rockwell: min 37
        • Brinell: min 341
      • impact Charpy-V, min --
  • Condilion H1000
    • Tempperature: 1000oF[540oC]
      • Tensile Strength, min, ksi[MPa]: 170[1170]
      • Yield Strength, min, ksi[MPa]: 160[1100]
      • Elongation Reduction in 2 in. [50mm] or 4D, min %: up to 12 in. Incl, L: 10; T:7
      • Reduction of Area, min %: up to12 in. Incl, L: 40; T:22
      • Hardness
        • Rockwell: min 37
        • Brinell: min 341
      • impact Charpy-V, min --
  • Condilion H1025
    • Tempperature: 1025oF[550oC]
      • Tensile Strength, min, ksi[MPa]: 150[1035]
      • Yield Strength, min, ksi[MPa]: 140[960]
      • Elongation Reduction in 2 in. [50mm] or 4D, min %: up to 12 in. Incl, 12
      • Reduction of Area, min %: up to12 in. Incl, 45
      • Hardness
        • Rockwell: min 34
        • Brinell: min 321
      • impact Charpy-V, min --
  • Condilion H1050
    • Tempperature: 1050oF[565oC]
      • Tensile Strength, min, ksi[MPa]: 145[1000]
      • Yield Strength, min, ksi[MPa]: 135[930]
      • Elongation Reduction in 2 in. [50mm] or 4D, min %: up to 12 in. Incl, L:12; T:9
      • Reduction of Area, min %: up to12 in. Incl, L:45; T:30
      • Hardness
        • Rockwell: min 34
        • Brinell: min 321
      • impact Charpy-V, min --
  • Condilion H1100
    • Tempperature: 1100oF[595oC]
      • Tensile Strength, min, ksi[MPa]: 130[895]
      • Yield Strength, min, ksi[MPa]: 105[725]
      • Elongation Reduction in 2 in. [50mm] or 4D, min %: up to 12 in. Incl, L:16; T:11
      • Reduction of Area, min %: up to12 in. Incl, L:50; T:30
      • Hardness
        • Rockwell: min 30
        • Brinell: min 285
      • impact Charpy-V, min --
  • Condilion H1150
    • Tempperature: 1150oF[620oC]
      • Tensile Strength, min, ksi[MPa]: 125[860]
      • Yield Strength, min, ksi[MPa]: 75[515]
      • Elongation Reduction in 2 in. [50mm] or 4D, min %: up to 12 in. Incl, L:18; T:12
      • Reduction of Area, min %: up to12 in. Incl, L:55; T:35
      • Hardness
        • Rockwell: min 26
        • Brinell: min 262
      • impact Charpy-V, min --

UNS S4500 / XM-25 Physical Properties

  • Density: 0.28 lbs/in3 7.75 g/cm3
  • Electrical Resistivity: ohm-cm: At 68 °F (20 °C): 0.0000992
  • Specific Heat: BTU/lb-°F (J/g-°C): 73 - 216 °F (23 - 102 °C): 0.114 (0.477)
  • Thermal Conductivity: BTU-in/hr-ft2-°F (W/m-K): Condition H900
    • At 70 °F (21 °C): 104 (15.0) At (200 °C): 18.2 W/m-K
    • At (500 °C): 24.4 W/m-K
  • Mean Coefficient of Thermal Expansion: in/in-°F
    • 75 - 200 °F: 5.88 x 10-6
    • 75 - 300 °F: 5.62 x 10-6
    • 75 - 400 °F: 5.68 x 10-6
    • 75 - 500 °F: 5.80 x 10-6
    • 75 - 600 °F: 5.91 x 10-6
    • 75 - 700 °F: 5.98 x 10-6
    • 75 - 800 °F: 6.09 x 10-6
    • 75 - 900 °F: 6.13 x 10·6
    • 75 - 1100 °F: 6.17 x 10·6
  • Modulus of Elasticity: ksi (MPa): 103 (193 - 200 x 103) in tension

UNS S4500 / XM-25 Thermal Properties

Properties Metric Imperial
Thermal expansion co-efficient ( @ 20-100°C/68-212°F) 10.1 µm/m°C 5.61 µin/in°F
Thermal conductivity (typical value for stainless steel) 20.7 W/mK 144 BTU in/hr.ft².°F

Machinability

UNS S4500 / XM-25 stainless steel alloy uses feeds and speeds comparable with other martensitic stainless steels. It is preferred to use positive feeds and slow speeds to achieve good results.

Welding

UNS S4500 / XM-25 stainless steel alloy can be welded using shielded methods to reduce contamination.

Hot Working

UNS S4500 / XM-25 stainless steel alloy can be hot worked by soaking at 1150-1177°C (2100-2150°F) followed by cooling and fully annealing.

Cold Working

UNS S4500 / XM-25 stainless steel alloy can be cold worked using all common techniques.
